Slow Gear Electronics Stereo Pedalboard Headphone Amp + Aux In

Sometimes, the importance of your signal routing solutions can be overlooked, especially with a complex, multi-unit pedalboard. Stereo pedals can be tricky as well, or summing to mono, or wanting a wider stereoscape to present to your audience. Luckily, there are pedals in existence like the Slow Gear Electronics Stereo Pedalboard Headphone Amp + Aux In, an excellent solution to create the greatest tone and signal amplification you’ve ever heard. Let’s see what this little beauty has to offer, shall we?

Includes an Aux input on 3.5mm TRS, separate mix knob, only outputs on headphones. Use for connecting a phone/PC for silent rehearsal. TS inputs and buffered outputs. No Aux on the buffered outs. L input is 1 Meg input impedance for direct connection of a guitar or bass. Buffered outputs are 47 Ohms output impedance. Connect to our M.A.I.D. for balanced XLR outs. Power comes in via standard Boss-style coaxial connector, center pin negative. 100 to 200mA supply depending on headphone impedance. Use up to 12V max for additional headroom. Will drive 8 ohm to 300 Ohm headphones or in ears via 1/4 inch TRS connector.

Features include:

TS stereo inputs. High impedance (1Meg) input on the L channel for direct input of an instrument.
TS stereo buffered outputs. Guitar only.
3.5mm stereo Aux input with mix knob.
Gain switch for Instrument vs Line level (affects only the headphone output.
Mono sum switch affects both buffered TS outs and the headphone out.
Polarity affects R input for buffered R out and headphone out.
Runs on 9 to 12Vdc only. Needs 100mA to 200mA depending on headphone impedance.
Output is LOUD, noise is low.
Pair this with our MAID (Micro Active Iso/DI) for a full pedalboard to PA solution.

In our demo below, we run through somerouting options, use the Stereo Pedalboard Headphone Amp with guitar and a drum machine, and more. I love how simple it is to make this unit work in any situation, and with just a couple switch flicks and knob turns, your whole musical world can open up. Gotta shout out Slow Gear Electronics for sending this pedal my way – be sure to check out their website for ordering and more info, cheers!!
